735167

氟掺杂氧化锡涂层玻璃载玻片

greener alternative

L × W × thickness 300 mm × 300 mm × 2.2 mm, surface resistivity ~7 Ω/sq

别名:

FTO 玻璃

登录 查看组织和合同定价。

选择尺寸

变更视图

关于此项目

UNSPSC Code:
12352103
EC Number:
242-159-0
NACRES:
NA.23
Material:
coating (Fluorine doped tin oxide)
Packaging:
1 ea of
Manufacturer/tradename:
Sigma-Aldrich
技术服务
需要帮助？我们经验丰富的科学家团队随时乐意为您服务。
让我们为您提供帮助

Quality Level

100

material

coating (Fluorine doped tin oxide)

description

Haze: 5%, Substrates and Prefab Devices

composition

SnO2/F

manufacturer/tradename

Sigma-Aldrich

packaging

1 ea of

greener alternative product characteristics

Design for Energy Efficiency
Learn more about the Principles of Green Chemistry.

sustainability

Greener Alternative Product

surface resistivity

~7 Ω/sq

L × W × thickness

300 mm × 300 mm × 2.2 mm

transmittance

80-82% (visible)

greener alternative category

Enabling

General description

载玻片上氟掺杂氧化锡的涂层厚度为∼ 550 nm。玻璃的折射率为∼ 1.52， SnO2:F涂层为∼ 1.85。
We are committed to bringing you Greener Alternative Products that adhere to one of the four categories of Greener Alternatives. This is an enabling product that enhances the performance of perovskite fuel cells, facilitating high solar energy conversion and contributing to more efficient energy solutions. Click here for more information.

Application

氟掺杂氧化锡镀膜玻片（FTO玻璃）可作为染料敏化太阳能电池(DSSC)和光伏电池(PV)的底物。

Still not finding the right product?

Explore all of our products under 氟掺杂氧化锡涂层玻璃载玻片

存储类别

13 - Non Combustible Solids

wgk

WGK 2

flash_point_f

Not applicable

flash_point_c

Not applicable
